Technical Parameters
|
Material: |
Aluminum body/Steel |
|
Surface Finishing: |
Polish /zinc plated |
|
Diameter: |
3.2mm, 4.0mm, 4.8mm, 6.4mm,(1/8, 5/32, 3/16,1/4) |
|
Customized: |
Customized |
|
Standard: |
IFI-114 and DIN 7337, GB, Non-standard |
Features
High strength Dome Head Stainless Steel/Aluminum inlock Structural Blind Rivet
Structural Blind rivets offer high strength, wide grip range, and excellent clamp-up force. This system provides a mechanical lock that delivers 100% mandrel retention. The mandrel also fills the body of the rivet to give greater shear strength.
• The mandrel is retained within the shear plane providing high strength under shear loads
• The internal lock ensures positive mandrel retention which results in high strength under tensile loads
• Typically used in manufacturing or truck body repair
•Head diameter is twice the body diameter, providing adequate bearing for nearly all applications
• Standard nosepieces can be used for installation.
